5 axis CNC Txhuas Profile Machining Chaw
Y / Z-Axis muab tso rau qhov tseeb: 0. 02 hli
Rov ua dua qhov tseeb: 0. 02mm
Khoom nta
● Nws nyob rau ntawm-line nrog ERP software thiab tuaj yeem paub tsis siv neeg machining los ntawm kev ntsuas.
● Cov ntaub ntawv tuaj yeem muab clamped nyob rau ib lub sij hawm los ua kom tiav txhua lub tshuab pom kev xws li lub ntsej muag, tsis txhob xauv lub ntsej muag, pneumatic tshuav lub qhov, mounting qhov thiab li ntawd.
● Yuav tau txais Gantry tus qauv nrog txav nqaj thiab kem, uas yog qhov ruaj khov thiab txhim kho cov rigidity ntawm cov cuab yeej siv tshuab.
● Tau txais cov khoom lag luam zoo yog cov servo motors.
● Cov khoom lag luam zoo tau ua haujlwm zoo rau servo motors, linear screws, linear yog sure kom ntseeg tau tias cov khoom muaj kev ua haujlwm siab. Siab ruaj khov thiab kev ntseeg tau. Kev pub mov lub zog yog ua ntej-ncab kom ntseeg tau tias qhov kev ruaj ntseg ntawm machining raug.
● Cov tshuab adops imported tsib-axis taub hau, uas tuaj yeem ua tiav cov machining ntawm txhua qhov chaw tsuas yog cov kab riam tsis siv neeg hloov pauv.
Cov khoom siv hluav taws xob tsis siv neeg tsis tuaj yeem siv lubrication nrog cov sij hawm kom muaj peev xwm ua kom ruaj khov ntawm lub tshuab.
● Txais pneumatic clamping rooj los txhim kho chaw thau khoom thiab thau khoom ceev.
● Tau txais cov renishaw interfullicometer nrhiav kom them nyiaj los ntawm qhov tseeb ntawm lub tshuab.
● Kev tiv thaiv kev nyab xeeb txoj kev tiv thaiv kev nyab xeeb kev nyab xeeb kom muaj kev nyab xeeb.
Yeem: Ntsug disc hom tuam hloov pauv.
Xaiv t-hom ua haujlwm rooj
Main Specifications thiab Kev Ntsuas Cov Lus
| X-axis muab qhov tseeb | 0. 03mm |
| Y / z-axis muab tso rau qhov tseeb | 0. 02 hli |
| Rov ua dua qhov tseeb | 0. 02 hli |
| X-axis stroke | 7000 ~ 10500 ~ 15500mm |
| Y-axis stroke | 630 {{3- axis, 510mm 4- Axis |
| Z-Axis stroke | 590mm |
| A-Axis stroke | ± 120 Qib |
| C-Axis stroke | 2 2 Qib |
| X-axis khiav ceev | 0} ~ 80m / min |
| Y-axis Khiav Ceev | 0 ~ 35m / min |
| Z-axis Khiav Ceev | 0 ~ 25m / min |
| Ntxaiv ceev | 16000TRPM |
| Taper ntawm ntxaiv qhov | HSK-F63 |
| Ntxaiv Hwjchim | 15kw |
| Tool Mag Mag Ntawv | Kaus daim ntawv |
| Tuam Mag Mag Mothoence | Txawb 12 Noj + Xed 1 Chaw Nres Tsheb (pom hniav) |
| Kev Cua Txias | Atomized cua txias |
| Lubrication system | Tsis siv neeg lubrication |
| Fixture Chaw Nres Tsheb | 8 |
| Kev siv roj | 15l / min |
| Zuag qhia tag nrho | 11300 * 2950 * 3500mm |
| Qho hnyav | Txog 7000kg |
Kev tsim khoom ntau lawm
